CRAWLER SKID STEER LOADER
Retractable Chassis for Adjustable Passage Width Hydraulic retractable crawler structure shrinks to 920mm for indoor transportation, and fully extends on soft outdoor ground to expand contact area, balancing indoor accessibility and outdoor anti-overturn stability.
Indoor Renovation: Construction waste removal, ground breaking, material transportation in narrow basements, decoration waste cleaning.
Model: ME270
Machine Operating Weight(Kg): 200
Engine Brand: Run Tong
Engine Model: 420
- Overview
- Recommended Products
CRAWLER SKID STEER LOADER
Product Overview
The Crawler Skid Steer Loader is an all-terrain multi-functional compact engineering machine, adopting an integrated chassis with crawler travelling and skid steering structure. Without steering axle, it realizes 360° in-place zero-radius rotation through differential speed of left and right crawlers. Equipped with standardized quick-change interfaces at front end, the machine can rapidly install dozens of attachments including digging bucket, log grapple, hydraulic breaker, snow sweeper, snow thrower, pavement milling head, plate compactor and hedge trimmer, integrating shoveling & transportation, concrete breaking, road cleaning, garden trimming, pavement milling, material grabbing and ground compaction in one single unit.
Fitted with widened rubber crawlers and reinforced frame, it can smoothly travel on muddy ground, sand, gravel, steep slopes and narrow yard sites without damaging paved surfaces. The compact overall dimension allows it to pass standard doorways, underground parking garages and indoor renovation construction sites. Operated by single person in standing position, it is widely applicable to municipal maintenance, landscape engineering, indoor demolition, farm breeding, small infrastructure, community property and winter snow removal. One machine can replace multiple single-function machinery, drastically cutting equipment investment and labor cost on construction sites.
Different from wheeled skid steer loaders with fixed narrow tires, this crawler version greatly expands terrain adaptability. The differential skid steering eliminates turning dead zones, making it flexible in ultra-narrow alleys, basements and yard corners where wheel models cannot access. The retractable undercarriage balances indoor passage size and outdoor anti-tipping performance. Universal quick couplings remove complicated tool replacement work, enabling fast switch between working procedures. The modular layout simplifies daily maintenance, while full customization options meet diversified demands of municipal, agricultural and snow removal industries. It has become a mainstream multi-purpose compact machine for small and medium construction teams, property management companies and large-scale farms.
| Model | ME270 | ME275 | ME290 | ME380 | ME35 |
| Machine Operating Weight(Kg) | 200 | 520 | 750 | 875 | 2400 |
| Engine Brand | Run Tong | Run Tong | Run Tong | Run Tong | Run Tong |
| Engine Model | 420 | 420 | 420 | R740 | 825D |
| Travel Speed(Km/h) | 0-6 | 0-6 | 0-6 | 0-6 | 0-6 |
| Bucket Capacity(m³) | 0.15 | 0.15 | 0.09 | 0.15 | 0.18 |
| Total length J/K(mm) | 2150 | 2050 | 2500 | 2055-2285 | 2660 |
| Fuel Type | 92-octane gasoline | 92-octane gasoline | 92-octane gasoline | 92-octane gasoline | 92-octane gasoline |
| Hydraulic Oil Tank (L) | 12 | 10 | 20 | 23 | 25 |
| Fuel Tank (L) | 5 | 5 | 10 | 28 | 25 |
| Maximum Working Height (mm) | 2350 | 1600 | 1882 | 2100 | 3019 |
| Maximum Lifting Weight (Kg) | 200 | 200 | 200 | 200 | 200 |
| Maximum Engine Power(Kw) | 8.5 | 8.5 | 8.5 | 24 | 32.6 |
| Engine Oil Replacement Capacity (L) | 1 | 1 | 1 | 1.6 | 2.4 |
| Tire | rubber track | rubber track | rubber track | rubber track | rubber track |
Specifications and Parameters
1.Rated Load Capacity: 700kg-1000kg, multiple configurations can be customized according to actual working requirements
2.Body Material:High-strength steel structure, equipped with wear-resistant, anti-slip tracks, suitable for all kinds of ground conditions.
3.Chassis Structure:Hydraulically retractable widened wear-resistant rubber crawlers
4.Control System: Dual integrated pilot joysticks, stepless hydraulic flow regulation
5.Brake System:Independent hydraulic parking lock for left & right crawlers, auto track locking when machine stops
6.Overall Dimensions: Compact body with narrow-aisle design, which can easily adapt to narrow and limited working spaces.
7.Frame Structure: Thick bent one-piece welded frame, reinforced integrated lift arm
8.Compliance: Fully complies with national special equipment safety standards and international ISO industry safety regulations
Product Features
1.All-terrain Crawler Travelling & Zero-radius Skid Steering Wear-resistant widened rubber crawlers deliver strong grip and can travel on mud, sand, lawn and asphalt without scratches. Differential control of left and right tracks supports 360-degree in-place turning, enabling flexible operation in narrow alleys, basements and yard corners inaccessible to wheeled skid steers.
2.Standard Quick-change Attachments, Multi-function All-in-one Universal front hydraulic quick couplings allow tool-free one-click switching of various engineering attachments, covering earthmoving transportation, stone grabbing, concrete breaking, road cleaning, green trimming and pavement milling. Multiple working scenarios do not require separate equipment.
3.Retractable Chassis for Adjustable Passage Width Hydraulic retractable crawler structure shrinks to 920mm for indoor transportation, and fully extends on soft outdoor ground to expand contact area, balancing indoor accessibility and outdoor anti-overturn stability.
4.Humanized Dual Pilot Control, Easy to Master Independent left and right pilot joysticks separately control travelling and working devices with self-adaptive flow regulation. Lifting, bucket retraction and attachment movements are smooth. New operators can finish independent operation within half an hour without professional training.
5.Thickened Lifting Arm & Reinforced Frame, Stable Under Heavy Load Integrated thick bent frame with double-layer reinforced front lifting arm generates minimal body shaking during full-load lifting and breaking work, resisting deformation and cracking after long-hour frequent material transportation and demolition tasks.
6.Modular Layout, Convenient Maintenance & Low Failure Rate All hydraulic pipelines are covered with wear-resistant outer sleeves. Filters, pins and hydraulic inspection points are centrally arranged for simple daily inspection and component replacement, controlling long-term service cost on stony and muddy construction sites.
7.Full-range Engineering Customization for Multiple Industries Customizable chassis width, lifting arm length, bucket capacity and complete supporting attachments. OEM private labeling including customized body color, brand logos and nameplates is supported. Exclusive tailor-made machines can be developed for municipal, landscape, agriculture and snow removal dedicated working conditions.
Application Scenarios
Municipal Maintenance: Pavement repair, road milling, garbage transportation, winter road snow sweeping & throwing, green belt trimming, manhole excavation and backfilling.
Landscape Engineering: Seedling transplanting, branch shredding, hedge trimming, landscape earthmoving transportation, stone grabbing and stacking.
Indoor Renovation: Construction waste removal, ground breaking, material transportation in narrow basements, decoration waste cleaning.
Farm & Breeding Farm: Feed transportation, manure cleaning, greenhouse soil turning, agricultural goods loading and unloading, fence material handling.
Small Infrastructure: Yard hardening, small ditch excavation, sand & stone transportation on construction sites, temporary ground leveling and compaction.
Community Property: Park cleaning, green maintenance, winter snow removal, goods transportation in underground garages, supporting work for minor maintenance.
Landscape Engineering: Seedling transplanting, branch shredding, hedge trimming, landscape earthmoving transportation, stone grabbing and stacking.
Indoor Renovation: Construction waste removal, ground breaking, material transportation in narrow basements, decoration waste cleaning.
Farm & Breeding Farm: Feed transportation, manure cleaning, greenhouse soil turning, agricultural goods loading and unloading, fence material handling.
Small Infrastructure: Yard hardening, small ditch excavation, sand & stone transportation on construction sites, temporary ground leveling and compaction.
Community Property: Park cleaning, green maintenance, winter snow removal, goods transportation in underground garages, supporting work for minor maintenance.
Frequently Asked Questions (FAQ)
Q1: What is the delivery lead time for customized crawler skid steer orders?
A1: Standard in-stock machines can be shipped within 3 working days. Custom orders with extended lifting arms, widened crawlers, complete attachment sets or private branding take 4–8 weeks, adjusted by total order quantity.
Q2: Will the rubber crawlers slip on muddy steep slopes? Can steel crawlers be installed instead?
A2: Widened tracks have large ground contact area with sufficient grip on regular gentle slopes and mud. Steel track assemblies are optional for mine and stony sites, with separate track spare parts available for later replacement.
Q3: How many attachments can one machine match? Is attachment replacement complicated?
A3: It supports more than ten attachments including digging buckets, hydraulic breakers, snow sweepers and log grapples. Standard tool-free quick couplings enable single-person replacement within 1 minute.
Q4: Can the crawler skid steer operate on indoor tiles and wooden floors for a long time?
A4: Original non-marking thick rubber crawlers will not scratch tiles, epoxy floors and lawns under normal driving, so it can be safely used in finished indoor decoration venues.
Q5: How stable is the machine during long-hour full-load lifting and breaking work?
A5: Double-layer reinforced lifting arm matched with integrated thick frame delivers minimal body shaking within rated load. Long-term operation exceeding rated load is strictly prohibited.
Q6: What daily maintenance items does the crawler skid steer require?
A6: Clean mud and sand stuck on crawlers every day, check track tension; replace hydraulic filters every 200 working hours, inspect wear of lifting arm pins and integrity of pipeline protective sleeves.
Q7: Does the machine support OEM customization of logos, body color and lifting height?
A7: Comprehensive OEM & ODM customization services are provided. We can adjust body color, brand nameplates, lifting arm length, chassis specifications and full attachments as required. Exclusive machines can be developed for municipal, agriculture and snow removal dedicated working conditions.
A1: Standard in-stock machines can be shipped within 3 working days. Custom orders with extended lifting arms, widened crawlers, complete attachment sets or private branding take 4–8 weeks, adjusted by total order quantity.
Q2: Will the rubber crawlers slip on muddy steep slopes? Can steel crawlers be installed instead?
A2: Widened tracks have large ground contact area with sufficient grip on regular gentle slopes and mud. Steel track assemblies are optional for mine and stony sites, with separate track spare parts available for later replacement.
Q3: How many attachments can one machine match? Is attachment replacement complicated?
A3: It supports more than ten attachments including digging buckets, hydraulic breakers, snow sweepers and log grapples. Standard tool-free quick couplings enable single-person replacement within 1 minute.
Q4: Can the crawler skid steer operate on indoor tiles and wooden floors for a long time?
A4: Original non-marking thick rubber crawlers will not scratch tiles, epoxy floors and lawns under normal driving, so it can be safely used in finished indoor decoration venues.
Q5: How stable is the machine during long-hour full-load lifting and breaking work?
A5: Double-layer reinforced lifting arm matched with integrated thick frame delivers minimal body shaking within rated load. Long-term operation exceeding rated load is strictly prohibited.
Q6: What daily maintenance items does the crawler skid steer require?
A6: Clean mud and sand stuck on crawlers every day, check track tension; replace hydraulic filters every 200 working hours, inspect wear of lifting arm pins and integrity of pipeline protective sleeves.
Q7: Does the machine support OEM customization of logos, body color and lifting height?
A7: Comprehensive OEM & ODM customization services are provided. We can adjust body color, brand nameplates, lifting arm length, chassis specifications and full attachments as required. Exclusive machines can be developed for municipal, agriculture and snow removal dedicated working conditions.
